● Implement hydraulic streering. ● Shuttle-type central balance pin. ● Irradiance can be adjusted and the range is large. ● Cast steel material is used for the axle body,which is good in rigidity and high in strength. ● The gap is high with good passability during operation. |
Front-wheel camber angle | 3° |
Kingpin inclination angle | 7° |
kingpin caster angle | 0° |
Toe-in of front wheel | 3-10 |
spoke range | 2110±3 |
Max.deflection | 45° （inside） |
Max.angle of swing | According to engineering machinery's demand |
Maximum load-carrying capacity | 6000 |
