● Adopted the integral casting steel bridge shell,the rigidity is good. ● Front axle steering,steering angle can up to 30°. ● The semi-axle is thickening and the transmission is more reliable. ● Applicable to 6-8 ton wheel excavators. |
rated load | 300Kg |
speed ratio of the main reducer | 6.167（37/6） |
font-wheel cmber angle | 7000N.m |
toe-in | 1-4mm |
corner of sheep wheel | 30° |
braking way | Air brake |
brake specification | Ф320×95 |
double diaphragm chambe | 124㎡ |
brake pressure | 0.6～0.8MPa |
oil mass | GL-4 85W/90 2.5L |
