    Loader Drive Axle

    HOME > PRODUCTS > Product Center > Loader Drive Axle > Loader Drive Axle

    ZL18S Wet-type Braking Drive Axle

    Product type: Loader Drive Axle

    Address:NO.257 Kangwang West Road,Feicheng City,

    Address:Shandong Province.

    Tel:+86.538 2095198   2095186   3302973   3302663

    After-sale service:+86.538 3302961   2095189   2095178

    Fittings department:+86.538 2095198 3302651

    Main connection dimensions

    Characteristics:

    ● The brake in enclosed multi-disc wet-type braking mode,with braking hub,hydraulic pressing,spring release and excellent braking performnce,is installed behind the planetray hub decelerating-gears.

    ● Suitable for the ZL20 wheel loader and the engineering machineries in similar conditions.

    Technical parameter

    Main transmission ratio
    6.667
    Hub transmission ratio
    3.23
    Tltal trasmission ratio
    21.53
    Axle olad
    8500Kg
    Input torque
    900N.m
    Brake
    Braking oil pressure
    5.5MPa
    Braking moment
    11000N.m/pce
